| Capacity | 512GB |
|---|
| Capacities | 512GB/1TB/2TB/4TB/8TB |
|---|
| Form Factor | M.2 2280 |
|---|
| Interface | PCIe Gen4x4 |
|---|
| Speed | 512GB: Read speed up to 7200MB/s, write speed up to 4400MB/s,; random read and write speeds of up to 800,000 IOPs; 1TB: Read speed up to 7400MB/s, write speed up to 6500MB/s,; random read up to 1,000,000 IOPs, random write up to 900,000 IOPs; 2TB: Read speed up to 7400MB/s, write speed up to 6500MB/s,; random read up to 1,000,000 IOPs, random write up to 900,000 IOPs; 4TB: Read speed up to 7400MB/s, write speed up to 6500MB/s,; random read and write speeds of up to 900,000 IOPs; 8TB: Read speed up to 7000MB/s, write speed up to 6200MB/s,; random read up to 850,000 IOPs, random write up to 900,000 IOPs |
|---|
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
|---|
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
|---|
| Dimensions (L x W x H) | 512GB-4TB：80 x 22 x 2.45 mm (3.15” x 0.87” x 0.10”); 8TB: 80 x 22 x 3.75 mm (3.15” x 0.87” x 0.148”) |
|---|
| Weight | 512GB-4TB：6g / 0.013 lbs; 8TB: 7.6g / 0.017 lbs |
|---|
| Warranty | Five-year limited warranty |
|---|
| Shock-resistant | 1500G, duration 0.5ms, Half Sine Wave |
|---|
| Vibration-resistant | 10~2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis (X,Y,Z) |
|---|
| TBW | 512GB: 500TBW, 1TB: 1000TBW, 2TB: 1500TBW,4TB: 3000TBW, 8TB: 6000TBW |
|---|
| MTBF | 1,500,000 Hours |
|---|
| Part Number | LNM790X512G-RNNNG |
|---|
